In this article we will discuss about the design of LaMont boiler with the help of a suitable diagram.
This boiler works on a forced circulation and the circulation is maintained by a centrifugal pump, driven by a steam turbine using steam from the boiler. For emergency an electrically driven pump is also fitted.
Fig. 12.22 shows a LaMont steam boiler. The feed water passes through the economiser to the drum from which it is drawn to the circulation pump. The pump delivers the feed water to the tube evaporating section which in turn sends a mixture of steam and water to the drum. The steam in the drum is then drawn through the superheated. The superheated steam so obtained is then supplied to the prime-mover.
These boilers have been built to generate of 45 to 50 tonnes of superheated steam at a pressure of 130 bar and at a temperature of 500°C.
